Basic Info.

Model NO.	E71T-1
Flux Containing	Not Containing Flux
Slag Characteristic	Alkaline
Extended Length	>20mm
Shielding Gas	CO2
Spool/Reel	D100, D200, D270, D300, K300
Transport Packaging	3tons/Pallet
Color	Copper
Splash	Low
Strength	High
Transport Package	Pallet
Specification	0.8mm 1.0mm 1.2mm
Trademark	WP
Origin	Shandong
HS Code	72292000
Production Capacity	30000tons/Year

Product Description

Chemical omposition of welding wire:(%)

Chemical omposition of deposited matal:(%) Mechanical properties of deposited metal:(%) Property:Our company's welding wire is produced by high technology of copper coating, which surface is smooth and shiny, the copper layer is uniform and tight. We adopt the alignment technology and the CO2 gas shielded welding wire has excellent welding technological properties: stable electric arc, low splashing, beautiful welding seams, high deposition efficiency, etc.This series of welding wire is suitable for all positions and semi-auto and automatic gas shielded welding.
Application:CO2 gas shielded welding wire is mainly used in the welding of low carbon steel and 500Mpa grade alloy steel structure parts. Also used in all kinds of 500 Mpa grade steel board and pipe welding work. It is widely used in the area of vehicles, bridges, construction machinery, pressure vessel, engineering structures and container buildings etc.
Diameter of wire& reference current(DC+)

Model NO.	AWS ER70S-6	Spool/Reel	D100, D200, D270, D300, K300
Shielded Gas	CO2	Specification	3tons/Pallet
Transport Package	OEM	Origin	CHINA
HS Code	72292000	Production Capacity	2000tons Per Months

Product Name	ER70S-6 CO2 gas shielded welding wires
Keywords	welding wire
Material	Stainless steel
Color	copper
Grade	ER70S-6
Size	Available Diameters:0.8mm / 0.9mm/ 1.0mm / 1.2mm / 1.6mm / 2.0mm / 2.4mm etc..
Weight	1KG/2KG/6KG /7KG/10KG /15KG/20KG per spool, or by bundle
Explanation	It has strong resistance to surface oxidation and oil stains on the base material,and low sensitivity to pores.
Used	bridges, buildings, shipbuilding,machinery, automobiles, pressure vessels, as well as for welding plates and pipes

	C	Mn	Si	S	p	Cu
standard value	0.06-0.15	1.40-1.85	0.80-1.15	≤0.035	≤0.025	≤0.50
sample value	0.080	1.510	0.920	0.020	0.016	0.200

C	Mn	Si	S	P	Cu
0.070	1.500	0.760	0.014	0.015	0.150

	Tensile strength δb(MPa)	Yield Point δ0.2(Mpa)	Elongation δ5(%)	AKV Impact Value (J)(-30ºC)	Shielding gas
Standard value	≥500	≥420	≥22	27	CO2
Typical value	558	472	27	98	CO2

Diameter of wire (mm)		Φ0.8	Φ1.0	Φ1.2	Φ1.6
current (A)		40-140	70-250	80-350	170-550
Arc voltage(V)		16-21	17-27	18-30	23
